Description
Tangent Theta 3-15×50 Model TT315M Product description
Tangent Theta 3-15×50 Model TT315M
General properties
| Manufacturer | Tangent Theta |
|---|---|
| Riflescopes series | Tangent Theta Professional Marksman |
| Made in | Canada |
| In production since | 2015 |
| Warranty | 10 years |
| SKU | 800102-0001c |
Optical properties
| Variable magnification | Yes |
|---|---|
| Minimal magnification. | 3.00 x |
| Maximum magnification. | 15.00 x |
| Diopter range | – 3.0 / + 2.5 dpt |
| Lens diameter. | 50.00mm |
| Min. exit pupil. | 3.50mm |
| Max. exit pupil. | 11.50mm |
| Min. field of view. | 2.80 m/100m |
| Max. field of view. | 12.80 m/100m |
| Min. eye relief. | 90.00 mm |
| Max. eye relief. | 90.00 mm |
| Fast focus eyepiece | Yes |
Turret properties
| Turret Type | Tactical |
|---|---|
| Zero Stop | Yes |
| Nr. Turret Turns | DT – Double Turn |
| Turret rotation direction | CCW |
| Elevation (mrad). | 11.62 mrad |
| Elevation (MOA). | 39.00 MOA |
| Windage (mrad). | 11.62 mrad |
| Windage (MOA). | 39.00 MOA |
| Elevation Per Turn | 6 mrad |
Reticle properties
| Reticle position | 1. focal plane – FFP |
|---|---|
| Reticle illumination | Yes |
| Illumination color | Red |
| Daytime-usable illumination | No |
| Auto Turn-Off | No |
Parallax properties
| Parallax adjustment | Yes – side focus |
|---|---|
| Parallax adj. range | 50 m – inf. |
Physical properties
| Length. | 347.00mm |
|---|---|
| Weight. | 760.00 g |
| Filled with | Nitrogen |
| Lens coating | Fully Multicoated |
| Tube diameter | 30 mm |
| Mount rail type | No |
| Objective diameter | 57 mm |
| Eyepiece diameter | 43 mm |
Special features
| Waterproof | Yes |
|---|---|
| Fogproof | Yes |
| Shockproof | Yes |
| Special features | 1. focal plane, Fast focus, Fogproof, Fully multicoated, Illuminated reticle, Parallax adjustment, Shockproof, Tactical Turrets, Variable, Waterproof |
| Built-in rangefinder | No |
