Description
Bare Tool – Battery and Charger not included
Features:
- 18V LXT BL AVT Cordless 18 mm (11/16) Rotary Hammer, SDS-PLUS, LED light
- BL Motor Delivers 0-1,100 RPM, 0-5,000 BPM and 1.7 Joules of Impact Energy for Faster Drilling
- Compact and lightweight for reduced operator fatigue
- Vibration absorbing housing and ergonomic soft rubber grip design for vibration absorption and comfortable operation
- BL motor with high power to weight and size ratio
- BL motor generates less heat buildup and is ideal for prolonged use in high production applications
- BL motor is electronically controlled to optimize battery energy use for up to 50% longer run time per charge
- BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
- BL motor efficiently uses energy to match torque and RPM to the changing demands of the application
- Dust cup connectable to Makita vacuum cleaner (country-specific): Suitable for upward operation: For cleaner work environment
- Built-in LED light with afterglow function illuminates the work area
- 2-mode operation for Rotation Only or Hammering with Rotation for multiple applications
- Side grip with elastomer soft grip
- One touch sliding chuck enables quick and easy bit changes
- Variable speed trigger allows operator to adjust speed based on materials or application
- Constant speed control automatically applies additional power to the motor to maintain speed under load
- Depth gauge for increased drilling consistency
- Conveniently located push button for rotation reverse
- Electric brake for maximum productivity
- Battery protection circuit protects against overloading, over-discharging and over-heating
- Optional hook is convenient for temporarily hanging the tool
Specifications:
| IMPACT ENERGY | 1.7 J |
| CAPACITY | Concrete: 18 mm (11/16) |
| Steel: 13 mm (1/2) | |
| Wood: 24 mm (15/16) | |
| BLOWS PER MINUTE (BPM) | 05,000 |
| NO LOAD SPEED (RPM) | 01,100 |
| SOUND PRESSURE LEVEL | 90 dB(A) |
| SOUND POWER LEVEL | 101 dB(A) |
| NOISE K FACTOR | 3 dB(A) |
| VIBRATION LEVEL | Hammer drilling into concrete: 7.5 m/s |
| VIBRATION K FACTOR | Hammer drilling into concrete: 1.5 m/s |
| DIMENSIONS (L X W X H) | w/ BL1860B: 288 x 89 x 215 mm (11-3/8 x 3-1/2 x 8-1/2) |
| SHANK TYPE | Hammer: SDS-PLUS Shank |
| NET WEIGHT | w/ Side grip: 2.1-2.9 kg (4.6-6.4 lbs.) |
