Name: Hesco 800 Series 4800LV Level IV Stand Alone Plate Shooter Cut – Multi Curve (SOLD INDIVIDUALLY)
SKU: MNBIM701415
Price: 19.35 USD
Availability: InStock

Description

(THIS PRODUCT IS MADE TO ORDER WITH A8-12 WEEKLEAD TIME)

Hesco 800 Series BI 4800LV Shooter Cut LevelIV Stand Alone Multi Curve Torso Plates

NIJ Level IV Law & Enforcement Shooter Cut Plates

HESCO 800 SERIES is designed to perform in fast moving, highly volatile environments requiring the ultimate in protection and maneuvrability

Using next generation materials, 800 SERIES plates are the lightest weight, highest quality plates in their class. Finished with a highly durable wrap and waterproof coating delivering unsurpassed quality in feel and performance..

Next Gen Spectra® Materials And Technology
Comfort Fitting Multi Curve Designs
Law Enfrocement Style Shooter Cut And Military Style Sapi Cut
Highly Durable, Waterproof, PolyurethaneCoated, Cordura® Nylon Wrap
Precision Quality Control

THICKNESS: 0.67 in (17 mm)

SHOOTER CUT – MULTI CURVE – TORSO PLATES

PART NUMBER	WIDTH x LENGTH	WEIGHT
4800LV-SH-MC-L	10.0 x 12.0 in(254 x 305 mm)	4.7 lb(2.1 kg)
4800LV-SH-MC-S	8.0 x 10.0 in(203 x 254 mm)	3.0 lb(1.4 kg)

Manufacturing Tolerances:

Thickness dimensions are ± 1/8 in (± 3 mm). Width and length dimensions are +0.00 to -0.25 in (+0.00 to -6 mm). All weights are ± 5%.

Hesco Testing Protocol

NIJ Certification of hard armor requires submission of 10” x 12” test plates which must demonstrate the ability to defeat specific rounds tested to a valid NIJ shot pattern, after exposure to a stringent conditioning protocol to simulate aging and wear. Level III requires six M80 rounds per plate.Level IV requires one AP M2 per plate.

For reduced thickness, the BI 4800LV does not have front face or back face foam layers and therefore does not meet the drop test or backface signature deformation requirements of NIJ Standard–0101.06. Otherwise, its ballistic performance is consistent with the BI 4800.

Hesco holds itself to a higher standard by publishing the minimum number of shots that each size plate can be expected to defeat under similar NIJ testing methods, as well as listing many additional threats not addressed under the NIJ Certification process. Those minimum numbers are shown here.

Thread Performance Matrix

800 SERIES		4800LV-SH-MC-L	4800LV-SH-MC-S
Lead Core	5.56 x 45 mm – MI93Max Velocity 3150 ft/s	3	3
	7.62 x 39 mm – M67Max Velocity 2390 ft/s	3	3
	7.62 x 51 mm – M80 *Max Velocity 2800 ft/s	3	3
MILD STEELCORE	5.56 x 45 mm – M855/SS109Max Velocity 3150 ft/s	3	3
	7.62 x 39 mm – M43Max Velocity 2390 ft/s	3	3
	7.62 x 54R – LPSMax Velocity 2850 ft/s	3	3
ENHANCEDPERFORMANCE	5.56 x 45 mm – M855A1Max Velocity 3050 ft/s	3	3
	7.62 x 51mm – M80A1Max Velocity 3050 ft/s	1	1
ARMOR PIERCING CORE	7.62 x 39 mm – APIMax Velocity 2390 ft/s	3	3
	7.62 x 54R B-32 – APIMax Velocity 2850 ft/s	1	1
	7.62 x 51 mm – M61Max Velocity 2830 ft/s (863 m/s)	1	1
	7.62 x 63 mm – AP M2 **Max Velocity 2900 ft/s	1	1
